PPR Pipe Making Machine with Multi Layer Co-extrusion for 20-110mm Pipe Size and PLC Control with Touch Screen

Rated Power : 2.2-22kw

Model Number : LB-63

Controlsystem : PLC Control with Touch Screen

Price : Negotiable（USD EUR）

Extrudertype : Single Screw Extruder

Automatic : Full Automatic

Supply Ability : 15 SETS PER MONTH

Contactor : Schneider

Brand Name : LB

Max Output : 150kg/h

Coolingmethod : Water Cooling Tank

Payment Terms : L/C,T/T

Pipe Size : 20-110mm; 3 layer

Pipediameterrange : 16mm - 110mm

MOQ : 1 SET

Delivery Time : 45 WOKING DAYS

Totalpower : 30kW - 100kW

Certification : CE/ISO

Pipe Diameter : 20mm-110mm

Place of Origin : ZHANGJIAGANG

Powersupply : 380V, 50Hz, 3 Phase

Packaging Details : NORMAL PACKAGE

Contact Now

PPR Pipe Making Machine Multi Layer Co-extrusion System For Indoor Water Supply Plumbing System
Product Overview

Our PPR Pipe Extrusion Line features advanced hot cutting technology, precise dimensional control, and flexible specifications to meet diverse manufacturing requirements.

Co-Extrusion Process

Co-extrusion involves sending two or more molten raw materials through a single die to produce multi-layer pipes with various colors or wall thicknesses. This process combines multiple plastics to create materials with distinct properties, opening new frontiers in material engineering and addressing complex manufacturing needs.

Co-extrusion also reduces costs by incorporating recycled and reground scrap within virgin material for applications like handrails, fences, tubing, structural components, and air-blown food containers.

Complete Extrusion Line Components
  • Single screw extruder
  • Co-extruder: For manufacturing marking lines on pipes or creating multi-layer pipes
  • Die head
  • Vacuum tank: Designed with single or double vacuum chambers based on diameter requirements
  • Cooling tank: Configured with one, two, or three tanks depending on diameter
  • Haul-offs: Available in double, three, four, six, eight, ten, or twelve haul-offs configurations based on diameter
  • Cutter: Options include no-scraps cutter or planetary cutter designs
  • Coiler/Tipping chute
Specifications
Model Pipe Diameter (mm) Extruder Extruder Power (kw) Capacity (kg/hr)
LB-63 16-63 SJ65/33 55AC 150
LB-110 20-110 SJ75/33 75AC 180
Product Images
PPR Pipe Making Machine with Multi Layer Co-extrusion for 20-110mm Pipe Size and PLC Control with Touch Screen
Production Line Overview
PPR Pipe Making Machine with Multi Layer Co-extrusion for 20-110mm Pipe Size and PLC Control with Touch Screen
Extrusion Die Head
PPR Pipe Making Machine with Multi Layer Co-extrusion for 20-110mm Pipe Size and PLC Control with Touch Screen
Vacuum Tank Process
PPR Pipe Making Machine with Multi Layer Co-extrusion for 20-110mm Pipe Size and PLC Control with Touch Screen
Equipment Component
PPR Pipe Making Machine with Multi Layer Co-extrusion for 20-110mm Pipe Size and PLC Control with Touch Screen
Production Machinery
PPR Pipe Making Machine with Multi Layer Co-extrusion for 20-110mm Pipe Size and PLC Control with Touch Screen
System Overview
